CNC Hydraulic Press Brake With Delem Controller DA69T CNC System

Product Details

Place of Origin: CHINA

Brand Name: FRIENDSHIP MACHINERY

Certification: CE, ISO

Model Number: WC67Y

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Wooden box, standard sea packing

Delivery Time: 25 working days

Supply Ability: 5 sets per month

Get Best Price
Highlight:

hydraulic press brake machine

,

sheet metal bending machine

Pressure:
100tons
Machine Width:
4000mm
Control System:
E21/ Delem DA52
Seal Ring:
Valque
Hydraulic Valve:
Rexroth
Machine Name:
Hydraulic Press Brake
Pressure:
100tons
Machine Width:
4000mm
Control System:
E21/ Delem DA52
Seal Ring:
Valque
Hydraulic Valve:
Rexroth
Machine Name:
Hydraulic Press Brake
CNC Hydraulic Press Brake With Delem Controller DA69T CNC System



CNC Hydraulic Press Brake With Delem Controller DA69T CNC System



Press Brake Machine and Shearing Machine



Hydrauilc tandem press brake





1. All steel welded structure, integrated treatment (vibration aging, heat treatment) heating to eliminate stress, have good rigidity and stability

2. Heat treatment of the rack, rigidity optimization verification on entire machine and the application of hydraulic compensation structure jointly ensure the bending precision of MB8 series Press Brakes.

3. Programming a product simply consists of introducing the characteristics of the material to be bent,the dimensions of the product and the necessary tooling & die.The optimizing software searches for the best bending cycle.

4. Rear block distance, upper stroke, electric adjustment, manual fine adjustment device, digital display.

5. Imports including linear transducer,pressure proportional valve and servo motor.

6. Ram stroke(Y1,Y2) and backgauge(X,R,Z) are controlled by controller automatically,high productivity.

7. Adopting Electro-hydraulic proportional servo synchronization. Optional point within stroke can be controlled.Repeat precision of Y axes: ±0.01mm, Parallism: 0.02mm. Strong ability of deviation resistance.

8. Backgauge adopts ball-bearing screw and rolling guideway,quick speed and high repeat positioning precision.X axes with resolution 0.1mm.



Model Nominal Pressure Working Table Length Distance of column Throat depth Maximum Opening Height Slide Stroke Motor power
WC67Y-40T/2500 400 2500 2000 200 320 100 4
WC67Y-63T/2000 630 2000 1600 250 320 100 5.5
WC67Y-80T/3200 800 3200 2700 320 400 150 7.5
WC67Y-100T/3200 1000 3200 2700 400 460 180 7.5
