5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner

China 5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner supplier
5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner supplier 5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner supplier 5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner supplier 5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner supplier

Large Image :  5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner

Product Details:

Place of Origin: CHINA
Brand Name: Friendship Machinery
Certification: CE, ISO, BV
Model Number: HTLP Series

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Steel framework and wire mesh
Contact Now
Detailed Product Description

5T Lifting Welding Positioner , Head And Tail Stock Elevating Weld Positioner





1. Detailed product description


        Welding positioner is special welding auxiliary equipment, suitable for welding deformation of rotary work to get ideal processing position and welding speed. Modification machine can use with operating machines, welding machine to compose the automatic welding center, which also can be used for manual operation of work-piece displacements. Workbench rotation adopted inverter step less speed regulation, and the speed precision is high. Remote control box can realize the remote operation of workbench, also can connect with operating machines, welding machine system to realize linkage operation.

        Welding positioner is mainly used for transformations of work-piece position,Modification machine is mainly used for transformations of work-piece position,so that the work-piece is in the best position to achieve the welding assembling or position the work required, in order to improve the work efficiency.

        According to the working state machine displacements, our company divided it into the following several categories: fixed tilting (TP), the head and tail lifting type (HTLP). According to customers' special needs, sometimes tail frame can also make portable.





2. Technical proposal



Type

Maximum loading

capacity

Table diameter

Revolve speed

Revolve motor

Lifting motor

Lifting speed

HTLP5

5000kg

1200mm

0-1.5rpm

2.2KW

2.2KW*2

700mm/min

HTLP10

10000kg

1500mm

0-1.0rpm

4KW

3KW*2

460mm/min

HTLP20

20000kg

2000mm

0-0.8rpm

7.5KW

4KW*2

300mm/min

HTLP30

30000kg

2500mm

0-0.8rpm

11KW

5.5KW*2

HTLP50

50000kg

2500mm

0-0.7rpm

15KW

7.5KW*2

HTLP100

100000kg

3000mm

0-0.5rpm

22KW

22KW*2





3. Product application


        With the working bench going up or going down, turning and manipulating, the work-piece stays in the best position for being welded or assembled.



4. Product advantage


● Convenient, high efficiency
● High quality
● Reasonable price
● Good service
