Australian Standard Fireproof Cabinet , Industrial Safety Cabinets For Flammable Liquids
Material | Cold Rolled Steel | Thickness | 1.5mm |
---|---|---|---|
Shelf | Galvanized Steel Shelf | Storage | Acid Or Corrosive |
Standard | OSHA 29 CFR1910.106 | Color | Yellow |
High Light | Fireproof File Cabinet,Fire Hose Reel Cabinets |
1. Main features
● Double wall construction with 38mm insulating air space for fire resistance.
● Over 1.2mm thick, fully welded, construction holds squareness for longer life, offering greater protection in a fire.
● 5cm leak tight sump at the bottom of cabinet’s maximally catches incidental drips.
● Door can be fully opened to 180°, easy to operate, three-point latch with a manual lock for better security.
● Standardized warning label is highly visible and anticorrosive.
● Unique spill-catcher shelves catch incidental drips and adjust on 6cm centers.
● Durable and chemical resistant, lead-free powder coat is painted inside and outside cabinets, minimizing the effects of corrosion and humidity.
● 2inches vents with integral flame arresters in both sides of every cabinet.
● In terms of OSHA, on outside side panel, there is built-in grounding static connector for easy grounding.
2. Specification
Model | Capacity (Gal/L) |
Dimension H*W*D (cm) |
Shelf | Type of door | N.W/ G.W (KGS) |
FSM004 | 4/15 | 56*43*43 | 1 | Single door/manual | 27.3/35 |
FSM022 | 22/83 | 165*60*46 | 2 | Single door/manual | 74.2/90 |
FSM030 | 30/114 | 112*109*46 | 1 | Double doors/manual | 114/133 |
FSM045 | 45/170 | 165*109*46 | 2 | Double doors/manual | 114/133 |
FSM060 | 60/227 | 165*86*86 | 2 | Double doors/manual | 144.2/166 |
