Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21

Place of Origin CHINA
Brand Name FRIENDSHIP MACHINERY
Certification CE, ISO
Model Number GSJ Series
Minimum Order Quantity 1
Packaging Details Standard packing
Delivery Time 30 working days
Payment Terms L/C, T/T
Product Details
Control Way NC Suitable Work-piece Carbon Steel
Power Hydraulic System E21
Warranty 1 Year Compensation No
High Light

hydraulic press brake machine

,

sheet metal bending machine

Leave a Message
Product Description



Sheet Metal Bending Machine With E21 , Hydraulic Press Brake Bending Machine



Steel Sheet Bending Machine, Aluminium Sheet Bending Machine



NC Hydraulic Press Brake





name numerical value unit name

numerical

value

unit
Male weigh strength 800 KN Main motor model Y132M-4
Length of worktable 2500 mm power 7.5 KW

Distance between columns

of body

2300 mm speed 1440 R/min
throat depth 300 mm Axial piston pump model 25MCY14-1B
Slider stroke 100 mm flow 25 L/min
Open height 320 min-1 pressure 31.5 Mpa
Slider travel speed No-load 60 mm/s Shape size length 3050 mm
Work travel 12 mm/s width 1400 mm
Return trip 75 mm/s high 2300 mm
