Magnetic / Humid Proof Industrial Safety Cabinets 2 Drawer for Government

Place of Origin China
Brand Name Friendship Machinery
Certification CE, ISO
Model Number JY Series
Minimum Order Quantity 1 set
Packaging Details Standard package
Delivery Time 30 working days after down payment
Supply Ability 100 sets per month
Product Details
High Light

flammable storage cabinets

,

acid storage cabinets

Leave a Message
Product Description



Magnetic / Humid Proof Industrial Safety Cabinets 2 Drawer for Government





1. Approvals


Magnetic-proof humid-proof performance: once 7,000 gauss super magnetic field is applied to cabinet wall, the inside magnetic strength is less than 4 gauss. It was type tested and approved by Jiangsu provincial testing facility and all series marked with CE.





2. Application


Government, Finance, Securities, Insurance, Army, Court, Procuratorate, Tax, Public Security, Confidentiality, IT, Measuring and Mapping, Pharmacy, Scientific research, Archives, Meeting center as well as large scale enterprises.





3. Stored material


Important magnetic medium archived such as magnetic disk, magnetic tape, micro disk, film, recorded audio visual data as well as U disk, VCD/DVD, mobile disk etc.
Valued metal material, semi-conductor and sensitive items etc.





4. Warning


● Magnetic proof has superior anti-shock feature, making it eligible where potential
earthquake is available (air compressor station, diesel engine station etc.).
● The cabinet door should be closed right after each storing or retrieving operation.





5. Product specification



Model

Drawers

Drawer dimension
(mm)

Packing dimension
(mm)

Outside dimension
(mm)

Weight
(kg)

Capacity
(L)

Color

JY280

7

1520*700*500

1550*755*560

150*524*309

120

280

Grey

JY320

9

1800*700*500

1830*755*560

150*524*309

140

320

Grey




6. Temperature and humidity reference for regular stored stuff



Storage type

Bearable temperature

Bearable humidity

Medium disk

55℃

85%

Picture stuff

65℃

85%

X-ray filmed stuff

65℃

85%

Audio-visual records

70℃

85%

Thermal paper, transparent painting
paper, special paper

100℃

85%

Parchment and vellum paper

50℃

85%




7. Technical specification



JY280

● Dimension: 1520*700*500mm
● Net weight( N.Wt ): 130kg
● Capacity: 280L
● Drawers: 7 Drawers
● Stored LTO tapes: 40×7=280
● Stored CDs: 100×7=700
● Stored DTA tapes: 96×7=672/1008
● Working voltage: 220±20V
● Maximum power: ≤200W
● Average power: 20W

JY320

● Dimension:1800*700*500mm
● Net weight( N.Wt ): 150kg
● Capacity: 350L
● Drawers: 9 Drawers
● Stored LTO tapes: 40×7=280
● Stored CDs: 100×7=700
● Stored DTA tapes: 96×7=672/1008
● Working voltage: 220±20V
● Maximum power: ≤200W
● Average power: 20W



● Remark: inner structure of above products is applicable to storage of magnetic medium. In the case of other material storage (i.e. electronic unit, camera and tools etc.), the inner structure could be adjusted as per customers’ requirement to improve space efficiency.





8. Ambient humidity against Stored stuff  (reference only)






Relative Humidity (RH)

Recommended stuff for storage

60%-45%

Antiques, bank notes, old books, fax paper, copy paper etc.

45%-35%

Lens, microscope, magnifying glass, telescope, magnetic record and disk, photo film, printing film, musical instrument, stamps, leathers, medicines, tea, coffee, cigarettes etc.

35%-20%

Advanced hardware, measuring instrument, electronic units, motherboard, metallic powder, semi-conductor, medical raw material etc.

10%-20%

Electronic unit, IC, BGA, samples, standard measuring tools, seeds, pollen, bulbous roots etc.
