Automatic H beam Welding Line , H beam Production Line , Automatic Welding Machine

Product Details

Place of Origin: China

Brand Name: Friendship Machinery

Certification: CE, ISO

Model Number: FSM Series

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Packaging Details: Standard package

Delivery Time: 30 working days after down payment

Get Best Price
Highlight:

h beam assembly machine

,

submerged arc welding equipment

Beam Width:
200-800mm
Beam Height:
200-2000mm
Beam Length:
4000-15000mm
Warantee:
14 Month
Welder:
Include
Machine Name:
H Beam Welding Line
Beam Width:
200-800mm
Beam Height:
200-2000mm
Beam Length:
4000-15000mm
Warantee:
14 Month
Welder:
Include
Machine Name:
H Beam Welding Line
Automatic H beam Welding Line , H beam Production Line , Automatic Welding Machine



Automatic H beam Welding Line



H beam Production Line



Automatic Welding Machine





        H beam is a kind of new economical structural steel. Compared with ordinary I beam, the internal stress of H beam is small, section modulus is big, weight is light, which causes structure weight reduce 30%-40%. Welded H beam is much lighter and thus save cost than hot-roll beam, it is a product for construction and easy to be used with light weight, high quality, fine appearance, wide range of application. After using H beams, 30%-50% construction time can be decreased and 5% usage area of the room can be increased, 10%-30% of steel can be saved and 20% of the integrated cost of construction can be decreased compared with hot rolled sections.



No. Model Name
1 GS-4000 CNC flame cutting machine
2 HG-1800 Automatic assembling machine
3 MZG-1000*2 Gantry type submerged arc welding machine
4 HYJ-40 Mechanical straightening machine
5 HP-1018 Shot blasting machine



● Height of the web: 200-1800mm

● Thickness of the web: 6-32mm

● Width of the flange: 200-800mm

● Thickness of the flange: 6-40mm

● Length of the h beam: 4000-15000mm
