Hydraulic H Beam Welding Line Heavy Duty H Beam Straightening Machine
High Light | h beam assembly machine,welded h beam line |
---|
Hydraulic H Beam Welding Line Heavy Duty H Beam Straightening Machine
1. Main proposal
No. |
Item |
Unit |
Specification |
1 |
Flange thickness |
mm |
8-80 |
2 |
Flange width |
mm |
200-800 |
3 |
Web height |
mm |
200-1500,2000,2500 |
4 |
H beam length |
mm |
4000-16000 |
5 |
Web thickness |
mm |
8-60 |
6 |
Hydraulic |
1 set, Chinese or other brand customer choose |
|
7 |
Straightening(leveling) speed |
mm/min |
6700 |
8 |
Roller table length |
mm |
24000 |
2. Main introduction
HYJ-60 hydraulic straightening machine is specially designed for the straightening of heavy-duty H beam, which has big different with the normal H beam straightening machine. It adopt the straightening principle of pressing wheel stretching at same axis line, and the up-pressing wheel is controlled by hydraulic cylinder to up/down moving. It has the advantages of equal receiving force on flange when straightening, small rebounding after straightening, simple structure and easy operation etc. The equipment is fitted with floating roller structure, which is hydraulic controlled. It is the very important equipment for producing Heavy duty H beam.
![]() |
H Beam Hydraulic Straightening Machine
Cranes manufacture, steel structure manufacture, bridge building, h beam build up, automatic light h beam welding, spot welding machine, steel fabrication. |
Steel box column processed on CNC machining center, to make sure good fitting and high strength
H beam welding line and H beam qutomatic production line include CNC flame cutting machine, Automatic h beam assembling machine, H beam welding machine, H beam straightening machine and Shot blasting machine. |
![]() |
