Product Details
Place of Origin: China
Brand Name: Friendship Machinery
Certification: CE, ISO
Model Number: SWR Series
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Packaging Details: Standard package
Delivery Time: 30 working days after down payment
High Efficient Wind Tower Welding Production Line Pipe Turning Rolls
1. Summary
Welding manipulator series is composed of auto welding mechanical equipment. It can use with welding rotator, widely applied to industries such as boiler, pressure vessel, petroleum, chemical industry and mechanism.the characters of machine and main dimension is designed according to auto welding process,its just the right equipment to improve welding quality and realize welding automation.
2. Description
● Auxiliary equipment for welding center.
● Automatic welding manipulator can be selected various welding power.
● Stretching of cross boom adapts AC frequency converter step-less.
● Speed control and runs with steady speed.
● Head equipped with electric cross slides, can adjust position of welding.
● Chain break-resistant and anti-slip device in boom to guarantee safety.
● Braking device can ensure column work in safe environment.
● Automatic flux feeding, recovering devices, wire feeder device, working platform and chair.
● Customized requirements are accepted.
3. Technical parameters
|
Model |
WM1010 |
WM2020 |
WM3030 |
WM4040 |
WM5050 |
WM6060 |
|
Effective vertical lifting stroke of boom (mm) |
1000 |
2000 |
3000 |
4000 |
5000 |
6000 |
|
Effective horizontal stroke of boom (mm) |
1000 |
2000 |
3000 |
4000 |
5000 |
6000 |
|
Boom lifting speed (mm/min) |
420 |
1000 |
||||
|
Boom retracting speed (mm/min) |
120-1200 |
|||||
|
Column rotation angle (°) |
Stationary or ±180 rotation |
|||||
|
Column rotation way |
Stationary or Manual or Electric (0.1rpm) |
|||||
|
Trolley traveling way |
Stationary or Manual or Electric (1000mm/min) |
|||||
