Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment

  • Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment
  • Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment
Place of Origin China
Brand Name Friendship Machinery
Certification CE, ISO
Model Number FSM Series
Minimum Order Quantity 1
Packaging Details Standard export packing
Delivery Time 30 working days
Product Details
High Light

h beam assembly machine

,

welded h beam line
Leave a Message
Product Description

Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment







       T panel multi-electrode longitudinal welder machine adopts double arc double wire single pool of carbon dioxide gas shielded high speed welding, welding speed can reach 0.85m/min, this machine can use 16-24 sets of OTC 600A welding power to weld 4-6 assembled longitudinal at the same time, match with seam tracking device and original imported welding smoke concentrate recovery & purification devices.





Welding way

Double arc double wire single pool or single arc singl wire

single pool carbon dioxide gas shielded welding

Welding method

Flat fillet welding two surfaces at the same time

Bulb steel size

220*10-450*35mm

Angle steel

250*100*9mm-600*200*13.5mm

T-bar

300*10/ 100 *17-850*11.5/ 300*25 mm

Distance between longitudinal

650-950 mm

Longitudinal length

4000-25000mm

Welding speed

200-900mm/min

Welding current&voltage control type

Centralized control

Welding seam track way

Auto-electronic tracking

Welding smoke dedusting way

Centralized dedusting





Crane Type H Beam Welding Line , Shipbuild Longitudinal Pole Automatic Welding Equipment 0
