Steel Simple Decoiler Machine , Light Street Light Pole Making Machine





    This machine used to spread the steel coil, leveling and cut to the request size.after manual feed into the leveling machine, as the cutting size, the unit will finish the leveling and cutting action.





a. Unit scope



No.

Item

Specification

1

Coil materials

Hot rolled plate Q235A

(account as the strength of materials)

2

Coil thickness

2-6mm

3

Coil width

800-1800mm

4

Coil weight

≤25t





b. Unit parameter



No.

Item

Specification

1

Leveling speed

8m/min

2

Leveling accuracy

2mm/m (related with original shape)

3

Scale length tolerance

±5mm

4

Main motor power

27kw

5

Machine floor area

24m*5.5m

6

Machine working direction

From right to left (face to console)





c. Parameters



No.

Item

Specification

1

Coil thickness

2-6mm

2

Maximum processed width

1800mm

3

Materials

Q235A, σb≤450mpa

4

Coil weight

≤25000kg

5

Coil diameters

 φ800-1800mm

6

Plate working speed

125mm/s



7



Motor

Model

Y200L2-6

Power

27kw

Rotate speed

960r/min

8

Leveling accuracy

≥3mm/m²

9

Machine weight

14500kg
