Steel Plate Electro Shearing Hydraulic Press Brake DELEM DA66T Controller

Product Details

Place of Origin: China

Brand Name: Friendship Machinery

Certification: CE, ISO

Model Number: FSM-PB

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: wooden pallet

Delivery Time: 20 working days

Supply Ability: 30 sets per month

Get Best Price
Highlight:

hydraulic press brake machine

,

sheet metal bending machine

Model:
We67K
The Maximum Shear Thickness:
10mm
Controller:
DELEM DA66T
The Sheared Steel Sheet Strength:
450N/mm2
Shearing Angle:
0.5-3°
Guide Rail:
HIWIN
Model:
We67K
The Maximum Shear Thickness:
10mm
Controller:
DELEM DA66T
The Sheared Steel Sheet Strength:
450N/mm2
Shearing Angle:
0.5-3°
Guide Rail:
HIWIN
Steel Plate Electro Shearing Hydraulic Press Brake DELEM DA66T Controller



Steel Plate Electro Hydraulic Press Brake Machine, Hydraulic Shearing and Prss Brake for Plate





1. The main character and use of the device



● This machine is widely used in light industry, aviation, shipbuilding, metallurgy, instrument, electrical appliances, stainless steel products, construction and decoration industry, especially suitable for urban construction, highway light pole, power pole, car girder work-piece processing and manufacturing, etc.



● This series hydraulic press brake machine, adopts steel weld structure; vibration aging to release stress, the device with good rigidity and stability; the whole frame with good rigidity, work is stable, safety and reliable, easy to operate.



● To adopts DA66T controller specialized used in CNC press brake machine from DELEM company, and adopts electro-hydraulic scale servo valve from BOSCH company, Germany, so the system work is stable, and with high make accuracy. On the system installed grating, electro-hydraulic scale valve, and electronic amplifier of valve to make a closed circle control system, thus inspect and control the relative location and synchronous accuracy between ram and worktable precisely, let the ram keep synchronous running, and assure the press brake depth and angle.





2. Technical parameters



Model Units WE67K-250T/4100
Nominal pressure kN 2500
Worktable length mm 4100
Distance between uprights mm 3120
Throat depth mm 400
Ram stroke mm 250
Max opening height mm 540
Ram speed Unloaded mm/s 60
Full-loaded mm/s 8
Return mm/s 70
Gear pump Model / CP1-63-P-10R
Flow L/min 63
Pressure Mpa 31.5
Working Pressure of hydraulic system Mpa 26
Main motor power kW 18.5
Quantity of control axial / 3+1 (Y1,Y2,X1,V)
Control system / DA66T (DELEM, Netherland)
The Net weight kg 15600
The overall dimension mm 4200×2100×3100



Steel Plate Electro Shearing Hydraulic Press Brake DELEM DA66T Controller 0

Back side view
