High Speed Wind Tower Production Line For Tank Longitudinal Seam Welding
Tourch Screen | Weilun, Taiwan | Welding Length | 1500mm |
---|---|---|---|
PLC | Panasonic, Japan | Welder | Panasonic, Japan |
AC Contractor | Siemens | Thermal Overload Relay | Siemens |
High Light | pipe turning rolls,weld manipulator |
High Speed Wind Tower Production Line For Tank Longitudinal Seam Welding
1. Work-piece information
● Material: carbon steel
● Diameter: 120-750mm
● Wall thickness: 1.5-3.0mm
● Length: less than 1500mm (2000mm/ 2500mm/ 3000mm)
● Welding torch rapid speed: 2000mm/min
● System working pressure: 0.3-0.3Mpa
2. Equipment introduction
The device is composed of welding host machine and control system, there is a cable connected into an complete machine through the host machine and control system, convenient to install and commission and some other work.
Standard welding machine mainly composed of main frame, key press type pneumatic fixture, welding core shaft, shaft bracket, gun running mechanism, lifting mechanism, the torch of pneumatic mechanism, a welding torch adjusting mechanism and pneumatic control system and other components.
