78m2/H Continuous PU Sandwich Panel Production Line PLC Control

  • 78m2/H Continuous PU Sandwich Panel Production Line PLC Control
Place of Origin CHINA
Brand Name FSM Brand
Certification CE, ISO
Model Number COLO-2020
Minimum Order Quantity 1
Packaging Details Standard export package
Delivery Time 3 monthese
Supply Ability 3-5 sets per month
Product Details
Spray Gun Automatic + Manual Spray Gun Pre-washing Treatment 1 Set
Drying Room 1 Set Spraying Room 1 Set
Curing Ovens 1 Set Conveyor Line 1 Set
High Light

Continuous PU Sandwich Panel Production Line

,

78m2/h PU Sandwich Panel Production Line

,

78m2/h Sandwich Panel making machine
Leave a Message
Product Description

Powder Coating Line

Automatic Painting And Spraying Line For Steel Construction Parts



1. Production procedure
Loading the work-piece → Automatic spraying & washing pretreatment → Drying oven → Feed work-piece to spray booth → Feed work-piece to curing oven → Exit the oven and let it cool naturally → Remove the work-piece



1 Main equipment dimension mm (L*M*T)4200X1850X2600
2 Weight kg 6000
3 Power supply   380V 50HZ 75KVA
4 Steel wire diameter mm 1.8-2.8
5 3D plate defect welding rate c/o <=1%(for single swface 30 panel)
<=3%(EPS <=80mm)
<=3%(for both surface of the 3D plate and the thickness of EPS <=80mm)
<=5%(EPS <=100mm)
<=5%(for both surface of the 3D plate and the thickness of EPS <=100mm)
6 GL plate diagonal error mm <=5
7 Production efficiency s/step or m2/h 0.5s/step or 78m2/h
4.5s/step 48m2/h
8 Stand of forming machine stands 19
9 Size of material mm (600~1000)×(0.4~0.8)×L
10 Material   EPS,PU,Mineral Wool
11 Suitable Material   Colored galvanized steel board
12 Controlling system   PLC



1 The equipment is used for welding 3D structural mesh plate by the slanting stell wires when the upper mesh plate and lower mesh plate and in-between panel of EPS is passed through the equiment.The equiment is also used for welding single surface stell wire mesh plate for external wall heat preservation.
2 Adopt wholly pneumatic operation mode with stable operation,good reliability and long equiment lifetime.
3 Adopt integrated pneumatic wire-clamping device for finishing the forward procedure.
4 Adopt the integrated self-adaptation wire-welding device for finishing the welding procedure.
5 Provice the self-checking function and the failure automatic alarm function with easy poreation adn easy maintenance.
6 Adopt PLC adn touch screen control,and can automatically finish to straighten,weld and cut the stell wire.
7 Can produce two kinds of panels with either dense or sparse insertion.



2. Powder coating plant components list
● Spraying & washing pretreatment

● Drying oven
● Powder spray booth
● Mono-cyclone recovery system
● Filters recycle system
● Powder curing oven
● Curing oven heating system
● Powder feed centre: 2 sets
● Manual spray gun with controller
● Automatic spray guns with controller
● Reciprocators (3.0m travel)
● Suspension type conveyor line with drive
● Electronic control system: 1 set
