Longitudinal CNC Drilling Machine , 6m CNC Drilling Machine For Metal Sheet

  • Longitudinal CNC Drilling Machine , 6m CNC Drilling Machine For Metal Sheet
  • Longitudinal CNC Drilling Machine , 6m CNC Drilling Machine For Metal Sheet
  • Longitudinal CNC Drilling Machine , 6m CNC Drilling Machine For Metal Sheet
  • Longitudinal CNC Drilling Machine , 6m CNC Drilling Machine For Metal Sheet
Place of Origin CHINA
Brand Name FSM
Certification CE, ISO
Model Number FSM-XBH
Minimum Order Quantity 1
Packaging Details Wooden pallet
Delivery Time 25 working days
Product Details
Machine Name CNC Drilling Machine Tapping M3-M16
Spindle BT40 X Axis Stoke 500mm
Y Axis Stoke 6000mm Z Axis Stoke 320mm
High Light

cnc plate drilling machine

,

cnc h beam drilling machine
Leave a Message
Product Description





Longitudinal CNC Drilling Machine



6m CNC Drilling Machine For Metal Sheet



1. Specification

Model XHW-500/ 6000
Working size L*W 6000*500mm
Maximum thickness 200mm

Vertical drilling head

 Quantity 1
Spindle taper BT40

Drilling diameter

Φ1-φ30mm
Tapping diameter M3-M16
Spindle speed 30-3000rpm
Spindle motor 3.7KW
Spindle nose to table distance 150-470mm



Gantry longitudinal movement

(X-axis)

 Maximum stroke 300mm
Moving speed 0-9m/min
Servo motor 2.4KW



Drive mode

 Guided by linear rolling guide; driven by AC servo motor and ball screw pairs



Power head lateral movement

(Y Axis)

 Maximum stroke 2000mm
Moving speed 0-9m/min
Servo motor 2.4KW



Drive mode

 Guided by linear rolling guide; driven by AC servo motor and ball screw pairs
Vertical ram feed movement (Z-axis) Maximum stroke 320mm
Moving speed 0-8m/min
Servo motor 2.4KW (brake motor)



2. Main configuration

Linear guide HIWIN Taiwan
Ball screw HIWIN Taiwan
CNC system KND Beijing, China
Servo motor and drive device KND Beijing, China
Servo main axis motor CTB Beijing, China
BT40 mechanical main axis Jingyao Beijing, China
Pneumatic cylinder Airtac Taiwan
Chip removal machine Hengte Beijing, China
Main element Omron Japan
