QC11Y-6x3200 Hydraulic Guillotine Shearing Machine , NC Hydraulic Swing Shearing Machine
Product Details
Steel Sheet Material | Q235A | COntroller | E21S |
---|---|---|---|
Steel Sheet Strength | 450N.M | Seals Ring | Valqua, Japan |
Mold Material | T8 | Electric Components | Schneider Or Siemens |
High Light | hydraulic guillotine shearing machine,cnc hydraulic shearing machine |
Product Description
QC11Y-8*3200 NC Guillotine Shearing Machine
1. Technical parameters
Model | Unit | QC11Y-8*3200 | |
Controller | / | E21S | |
Maximum shear thickness | mm | 8 | |
Maximum shear width | mm | 3200 | |
Sheared steel sheet strength | N/mm2 | 450 | |
Shearing angle | ° | 0.5-2 | |
Times of strokes | per/mm | 12-30 | |
Blade length | mm | 3200 | |
Distance between vertical columns | mm | 3300 | |
Back gauge range | mm | 20-600 | |
Throat depth | mm | 100 | |
Work table height | mm | 800 | |
Main motor power | KW | 11 | |
Gear pump | Model | / | CP0-20-P-10R |
Flow | ml/r | 20. | |
Pressure | Mpa | 31.5 | |
Electrical system | V/Hz | 3P, 380V, 50HZ | |
Net weight | kg | 7700 | |
Overall dimension | mm | 3800*1700*2100 |
2.Main components manufacturer
Component name | Specification | ||
Blade | Material | 6CrW2Si | |
Manufacturer | Shanghai Shangpin Blade Producing Co., Ltd. | ||
Main Motor | Type | Y type | |
Manufacturer | Jiangsu Hengli | ||
Main electric components | Siemens | ||
CNC controller | Type | E21S | |
Manufacturer | Estun automation co., ltd. | ||
Hydraulic system | Pump | Type | Gear pump |
Manufacturer | HIGH-TECH Fluid Power Co., Ltd. | ||
Valve | HaiMen Xinli | ||
Seals | VALQUA, Japan |
