Product Details
Place of Origin: CHIA
Brand Name: FRIENDSHIP MACHINERY
Certification: CE, ISO
Model Number: QC11Y
Payment & Shipping Terms
Minimum Order Quantity: 1
Packaging Details: Standard pakcing
Delivery Time: 30 working days
Supply Ability: 5-10 sets per month
NC System: |
E21S |
Blade Material: |
6CrW2Si |
Main Motor: |
Jiangsu Hengli |
Main Electric Components: |
Siemens Or Schneider |
Seals: |
VALQUA, Japan |
Hydraulic Pump: |
HIGH-TECH |
NC System: |
E21S |
Blade Material: |
6CrW2Si |
Main Motor: |
Jiangsu Hengli |
Main Electric Components: |
Siemens Or Schneider |
Seals: |
VALQUA, Japan |
Hydraulic Pump: |
HIGH-TECH |
Guillotine Type NC Hydraulic Metal Shearing Machine QC11Y -16mm Higher Cut Accuracy
1. Technical parameters
| Model | Unit | QC11Y-16×4000 |
| Maximum shear thickness | mm | 16 |
| Maximum shear width | mm | 4000 |
| Sheared steel sheet strength | N/mm2 | 450 |
| Shearing angle | ° | 0.5-2.5 |
| Strokes | min-1 | 8-15 |
| Blade length | mm | 4100 |
| Distance between uprights | mm | 4230 |
| Back gauge range | mm | 20-600 |
| Main motor power | KW | 22 |
2. The device structure and character
● This device main used to cut mild carbon steel sheet with the thickness range from 3mm to 16mm, and the width less than 4000mm.
● Adopts rectangle blade, four cutting edges to be used. Prolong life, shear angle is adjustable, then reduce steel sheet cut warp and deformation.
● Up blade adopter adopts falling-in type, easy to blank, and can to higher cut accuracy.
● With the performance to section cut.
● Electric controller system: EC21S (Estun automation co., ltd).
3. Guarantee
Duration of warranty of the machine is 12 months (except any consumable parts and working tools) from the date of Certificate of Goods hand-over, except any miss operation of artificial ignorance. If the device happens fault or quality problems, seller should write reply in 5 hours (except nighttime) effetely after receive fault notice from buyer (Chinese and English copy), the seller is responsible for settling and bearing all charges and expenses related to the costs for workmanship and materials caused from faulty designed of the machinery and/or poor workmanship within the period of warranty (repairing, sending new parts, etc.). After warranty, seller supply paid service.
