Gantry CNC Plasma Cutting Machine , Plasma Cutting Machines
Plasma | Hypertherm Maxpro200 | Cooling Mode | Water Cooling |
---|---|---|---|
Control Software | StarCAM, China | Cutting Head | One Plasma And One Flame |
Height Controller | HYD Or Ontime, China | Cutting Thickness | 0-32mm |
High Light | flame cutting machine,pipe bevelling machine |
1. Performance index
- Cutting shape: It can cut Arbitrary steel part of planar shape constructed by programmable cutting straight line and circular arc
- CNC system and Mached Torch Height controller: STARTFIRE (China domestic famous brand)
- Strong Machine Frame to make the macine durable use
- Drive Mode: adopt step-by-step driving technology(servo motor driving optional)
- Running gear: adopt zero clearance wheel gear and rack transmission to make sure the running accuracy
- USB Interface: the machine can read ArtCAM,CAD,FASTCAM,StarCAM profiles etc.
2. Product Parameter
ITEM | PARAMETER | |
Model | Gantry type plasma cutting machine | |
Cutting method | Plasma and Flame | |
Maximum cutting width | 3000mm | |
Maximum cutting length | 7000mm | |
Cutting torch lifting stroke | ≤100mm | |
Cutting speed | 0-8000 mm/min | |
Maximum idle speed | 15000mm/min | |
Running accuracy | ≤ 0.005mm |
