1530 CNC Fiber Laser Cutting Machine , CNC Plasma Cutting Machine For Sheet
Fiber Generator | Raycus 500W | Nesting Software | Cypcut |
---|---|---|---|
Cooling Method | Water Cooling | Working Size | 1500*3000mm |
Precision | 0.05mm | Driving Motor | Yaskawa Sero Motror |
High Light | cnc plasma cutter,pipe bevelling machine |
high precision cnc fiber laser cutting machine for metal sheet
Model | FSM-GSJ-3015 |
Working platform | Sawtooth worktable |
Cutting thickness | Up to 10mm for stainless steel, 20mm for carbon steel, 8mm for aluminum/ brass/ copper |
Laser power | 1000W/1500W/2000W/3000W |
Position type | Red light position system |
Maximum Idle running speed | 120m/min |
Working humidity | 5%-95% |
Working temperature | 0-45℃ |
PowersSupply | 380V/50Hz or 60HZ |
Weight | 7000KGS |
Power | ≤20KW |
2. Cutting table
Cutting material and thickness | ||||
Carbon steel | 0.4-12mm | 0.4-14mm | 0.4-16mm | 0.4-20mm |
Stainless steel | 0.4-5mm | 0.4-6mm | 0.4-8mm | 0.4-10mm |
Aluminum | 0.4-3mm | 0.4-4mm | 0.4-6mm | 0.4-8mm |
Brass | 0.4-3mm | 0.4-3mm | 0.4-3mm | 0.4-8mm |
Laser power | 1000w | 1500w | 2000w | 3000w |
3. Fatures
- Spare parts:Servo motor from Japan, reduction gear and guide rail,etc are from Taiwan or Japan with original packaging.
- Accuracy:Its speed and accuracy are guaranteed by using gear grinding with high precision,imported guide rail and laser cutting head under strict assembly.
- Cutting:The laser cutting head which is imported from USA Lasermech with original packaging coordinates with spare parts which have high speed and precision to bring superb cutting quality.
