H Beam Fit Up Assembling Machine , Automatic H Beam Production Line Welding Machine
Product Details
Welding Width | 4000mm | Welding Length | 15000mm |
---|---|---|---|
Voltage | 380V/ 50HZ | Warranty | 1 Year |
Control Way | PLC | Welder | MIG Welder, KR350 |
High Light | h beam assembling machine,submerged arc welding machine |
Product Description
H Beam Fit Up Assembling Machine
Automatic H beam Production Line Welding Machine
1. Technical parameter
No. | Item | Specification |
1 | Model | FSM-ZL-14 |
2 | Dimension | 14000*1830*880mm |
3 | Effective width | 350-580mm |
4 | Effective length | Within 13500mm |
5 | Maximum pressure | ≤15MPs |
6 | Hydraulic oil type | 46# |
2. Configuration list
No. | Item | Note |
1 | Oil pump model | Gear pump |
2 | Oil pump discharge capacity | 10ML |
3 | Motor brand | Great wall |
4 | Motor model | Y132M-4 |
5 | Motor power | 5.5KW |
6 | Selector valve model | 34SM-L10H-T |
7 | Oil pump model | HSG63 |
8 | Worktable operate method | Manual |
9 | Cylinder control method | Separately control |
10 | Web adjust method | Through sub-plate to fit flange height |
