CE 54mm Roller 78rpm Cnc Threading Grinding Machine Right Spindle Feed

Product Details

Place of Origin: CHINA

Brand Name: FRIENDSHIP MACHINERY

Certification: CE, ISO

Model Number: GS

Payment & Shipping Terms

Minimum Order Quantity: 1

Packaging Details: Wooden box, standard sea packing

Delivery Time: 25 working days

Supply Ability: 5 sets per month

Get Best Price
Highlight:

78rpm cnc threading machine

,

54mm roller cnc threading machine

,

CE cnc thread grinding machine

Roller Diameter:
54mm
Roller Thickness:
100mm
Processing Diameter:
6-42mm
Spindle Speed:
78rpm
Machine Name:
Threading Machine
Certificate:
CE
Roller Diameter:
54mm
Roller Thickness:
100mm
Processing Diameter:
6-42mm
Spindle Speed:
78rpm
Machine Name:
Threading Machine
Certificate:
CE
CE 54mm Roller 78rpm Cnc Threading Grinding Machine Right Spindle Feed



Thread Rolling Machine For Making Anchor Bolt



Bar CNC Drilling And Threading Machine



Threading Rolling Machine



1.Two spindle of the machine rotates synchronously in the same direction .Right spindle feed motion in the horizontal direction under the rolling drive.Two rolling wheels make the work as required and other thread shape by rolling.
2.This machine is mainly composed of an organism, rotating box, fixed spindle seat , a movable spindle seat, hydraulic system and electrical parts etc.
3.The fixed seat and the movable seat main function is installing the screw rolling wheel and adjusting the rolling wheel tooth.
4.This machine is a hydraulic power system, it is mainly to make the active spindle seat to feed and return
5.The two spindle seat adjust center respectively.Angle of table axis can be adjusted in the plus or minus 3 degrees.Each shaft to feed the workpiece can be determined according to the parameters of workpiece and mechanical properties of materials.

Model
GS42
Distance from spindle center
150-300mm
The rolling press
200KN
Active force
11kw
Thread rolling wheel diameter
220mm
Roller diameter
12-100mm
Thread rolling wheel width
160mm
Thread rolling round aperture
75mm
Spindle speed
20,25,31,41,51,64r/min
Length of thread
unlimited
Size
1790*1730*1430mm
The cooling power
0.12kw
Hydraulic power
5.5kw
Weight
1800kg



CE 54mm Roller 78rpm Cnc Threading Grinding  Machine Right Spindle Feed 0
