Pipe Flange Small Manual Welding Positioners Adjustable 0-90 Degree

Place of Origin China
Brand Name Friendship Machinery
Certification CE, ISO
Model Number WP Series
Minimum Order Quantity 1 set
Price USD1,600 for 0.3tons loading capacity
Packaging Details Standard package
Delivery Time 30 working days after down payment
Supply Ability 30 sets per month
Product Details
High Light

column and boom welding manipulators

,

weld positioner

Leave a Message
Product Description



Pipe Flange Small Manual Welding Positioners Adjustable 0-90 Degree





1. Main introduction



● Adopting advanced permanent magnet DC and step-less speed regulating motor to drive working table turning.
● Working table can be overturned(0-90 degrees).
● Compact conformation, small dimension, light weight,easy operation, reliable quality.
● It's an ideal welding equipment which is suitable welding flange, hard pipe, round object,circular object and so on.
● According to requirement from customers,the chuck clamp, tail-stock, adjustable-welding gun support are available to meet automatically welding.





2. Technical specifications



Specification

WP3

Maximum load capacity

0.3T

Power

Rotation

0.37kw

Tilt

Manual

Maximum centroid height

200mm

Maximum centroid eccentricity distance

150mm

Working table

Rotation speed

0.1-1.0rpm

Tilt speed

Manual

Diameter

600mm

Maximum rotation diameter when tilting 90°

800mm

Worktable tilting angle

0-90°

Dimensions L*W*H

930*660*720mm

Weight

300kg







Pipe Flange Small Manual Welding Positioners Adjustable 0-90 Degree 0

Europ model welding positioner



Welding positioner can lift, turn and rotate the work piece to make the work piece to be in the best welding position. We produce side type, elevator type, double rotary type and others. The welding positioner we produced can be matched with welding manipulator to be welding centre, and can also be matched with robotic machine to realize automatic welding operation.



If you want know more information please let me know, we are Friendship Machinery Co., LTD.
