1T advanced Small Welding Positioner equipment , Turntable Weld Manipulator CE

Place of Origin CHINA
Brand Name FRIENDSHIP MACHINERY
Certification CE, ISO
Model Number WR SERES
Minimum Order Quantity 1
Price USD2200
Packaging Details Standard sea package
Delivery Time 25 working days
Supply Ability 30 sets per month
Product Details
Tilt Degree 0-90 Degree Loading Capacity 1T
Worktable Diameter 1200mm
High Light

column and boom welding manipulators

,

weld positioner

Leave a Message
Product Description

1. Simple introduction



    This machine is a kind of our advanced welding positioner equipment, which is be researched and manufactured absorbing domestic and international advanced positioner equipment.

The worktable is tilted by motor, accurate and reliable positioning. It makes the work-piece in perfect position for welding. The worktable adopts AC frequency conversion speed, so large range of variable speed and high precision, weld at need speed. Accordingly this device has advantages of compact structure, small cubage, beautiful shape, lightweight, convenient operating and so on. The machine can assort all kinds of auto welding or manual welding, improving welding quality, lessening welding labor and improve productivity.



    This machine can be used at automatic welding or manual welding, such as pipe horizontal welding, tube end welding, axle, tray and barrel, it can be widely used in the pressure vessels equipment, metallurgy, electric power, chemical machine industry etc.





2. Technical parameter



No. Item Specification
1 Loading capacity 5T 10T
2 Power Rotation motor 2.2KW 3KW
Tilt motor 3KW 5.5KW
3 Maximum gravity height 300mm 400mm
4 Maximum centroid eccentricity 200mm 200mm



5



Working table

Diameter 1500mm 2000mm
Rotation speed 0.05-0.5rpm 0.02-0.2rpm
Tilt speed 0.14rpm 0.14rpm
6 Tile angle 0-120 degree 0-120 degree
7 Package dimensions 2.2*1.5*1.45m 2.7*2*1.85m
8 Weight 3.7T 5.8T
