Professional Horizontal CNC Milling Machine with Adjustable Head
High Light | h beam straightening machine,h beam assembling machine |
---|
Professional Horizontal CNC Milling Machine with Adjustable Head
1. Key Specifications:
● Used for milling the two end face of H-beam and box-beam
● The power head angle can be adjustable by manual in a vertical plane in order to milling the groove
● Hydraulic work-piece clamping rack as option which can press the steel sheet
● And the top of the machine is opened, this design is good for work-piece lifting and transportation
● It takes the advantage of convenience, simplicity and fast adjusting
● The standard model is: DX1215 and DX2025
● The section size: 1200*1500 and 2000*1500mm
● Other parameter please check the parameter table, we also can special design for customer's according to their requirement
● The angle of power head in vertical surface: 0 to 45°
2. Technical parameters:
Model |
DX1215 |
DX1520 |
Section height |
1200mm |
1500mm |
Section width |
1500mm |
2000 mm |
Milling head power |
5.5KW |
|
Vertical milling speed |
55-500 mm/min |
|
Horizontal milling speed |
50-440mm/min |
|
Milling angle |
0-45° |
![]() |
H beam end face milling machine
Control panel |
