Metal Sheet CNC Plasma Cutting Machine , CNC Fiber Laser Cutting Machine Manufacturer
| Place of Origin | China |
|---|---|
| Brand Name | Friendship Machinery |
| Certification | CE, ISO |
| Model Number | FSM Series |
| Minimum Order Quantity | 1 set |
| Packaging Details | Standard package |
| Delivery Time | 30 working days after down payment |
Product Details
| Machine Name | CNC Fiber Laser Cutting Machine | Laser Generator | Raycus |
|---|---|---|---|
| Servo Motor | Yaskawa | Cutting Head | WSX |
| Software | Cypcut | Chiller | S&A |
| High Light | flame cutting machine,pipe bevelling machine |
||
Product Description
Metal Sheet CNC Plasma Cutting Machine
CNC Fiber Laser Cutting Machine Manufacturer
500w / 1000w / 2000w Fiber Laser Cutting Machine for Sheet Metal
CNC fiber laser cutting machine adopts China top brand Raycus laser generator, combining self-design Gantry CNC machine and high strength welding body. It's used High and low exchange platform to ensure stable cutting machine with high-efficiency and high-performance CNC system.It's professionally used for cutting 0.5-20mm carbon steel plate, 0.5-10mm stainless steel plate, galvanized plate, electrolytic plate, silicon steel, 0.5-10mm aluminum alloy, 0.5-8mm brass and copper and other thin metal materials.
| Rated uotput power | Optional |
| Working area (length x width) | 3000*1500mm |
| X Y Z axis position accuracy | ±0.05mm |
| X Y Z repetition accuracy | ±0.03mm |
| X Y axis max position speed | 120m/min |
| X Y axis max acceleration | 1.5G |
| Notch gap width | 0.1-0.3mm |
| Cutting accuracy | ±0.1mm |
| Min setting unit | 0.001mm |
| Installed capacity | 45KVA |
| Rated voltage | 380V |
| Countinuons working time | 24 hours |
| Frequency | 50/60Hz |
