Table Type CNC Plasma Cutting Machine For Sheet 1500*3000mm , LGK200 Plasma Cutting
Plasma | Hypertherm/ CUT200 | Suitable Work-piece | Carbon Steel |
---|---|---|---|
Cooling | Water Cooling Chiller | Working Size | 1500*3000mm |
Software | StarCAM, China | Driving Motor | Panasonic |
High Light | cnc plasma cutter,pipe bevelling machine |
Table Type CNC Plasma Cutting Machine For Sheet 1500*3000mm
LGK200 Plasma Cutting
Plasma cutting machine
1. Main Features
- Portable monoblock construction with small footprint.
- Easy installation,
- Dual side AC servo Y motorization with direct planetary gear box, helical rack and pinion drive system
- Precision Linear Rail Guide Ways in X and Y axis
- High speed torch lifter with automatic arc voltage height control
- Fully enclosed hose and cable carriers
- Hypertherm Micro Edge Pro CNC
- Integrated downdraft table with CNC electro pneumatic multi zone selection
- Integrated dross bins
- Magnetic Torch anti collision protection system
- Laser pointer for plate alignment
- CE safety specifications
2. Specification
SPECIFICATIONS FOR CNC PLASMA CUTTING MACHINE |
|||
No. | Name | Value | Unit |
1 | Table Width | 1500 | mm |
2 | Length Table | 3000 | mm |
3 | Under Torch Height | 150 | mm |
4 | Width Machine | 2350 | mm |
5 | Length Machine | 4450 | mm |
6 | Height Machine | 1750 | mm |
7 | Height Table | 850 | mm |
8 | X-axis | 1500 | mm |
9 | Y-axis | 3000 | mm |
10 | Weight | 3550 | Kg |
11 | Maximum (X-Y) Positioning-speed | 30 | m/min |
12 | Total Power Consumption (without Plasma system ) | 4 | Kw |
